DPN N Vigi RCBO

Act 9 DPN N Vigi RCCB with Over Current Protection (RCBO) up to 40AAct 9 DPN N Vigi RCCB with Over Current Protection (RCBO) up to 40AFeaturesNominal...

DPN N Vigi RCBO top picks

Schneider

26970

View Product

Act 9 DPN N Vigi RCCB with Over Current Protection (RCBO) up to 40A

Act 9 DPN N Vigi RCCB with Over Current Protection (RCBO) up to 40A


Features

  • Nominal current: 6A to 40A
  • Tripping Curve: C
  • 30mA sensitivity: additional protection against direct contact (in accordance with IEC 364)
  • 300mA sensitivities: additional protection against fire and indirect contact (in accordance with IEC 364)
  • Class AC - for normal installation
  • Class Si (New) - for electrically disturbed networks (with harmonics, pulsating DC components etc.) & for harsh environments (presence of corrosive atmosphere, chemical gases, humid location  etc)
  • Conforms to IEC/EN 61009-1
  • CE marked
  • Suitable for additional Protection and Indication auxiliaries: ON/OFF, Trip, Shunt trip, Undervoltage trip, Overvoltage trip, Communication Auxiliary

Benefits

  • Compact 2poles 2module version
  • Easy monitoring: Earth fault indication on front face
  • Immunity against nuisance tripping
  • New SI RCDs offers enhanced immunity to electrical disturbances and polluted & corrosive environments
  • Ensures no accidental contact with live part – Finger-proof IP-20 terminals
  • Avoids false insertion of cables and loose termination with Pull up terminals
  • 100% recyclable & recoverable materials.

Applications

  • Protection in all industrial and commercial buildings against:
    • Electrocution (in accordance with installation standard IEC 60364 and national standards)
    • The risk of fire due to current leakage into building electrical installations.
  • Protection of wires and cables against Overload and Short Circuit current fault
